Showgear PSA 32A6S Krachtstroom verdeler met uitlezing

Prijzen vanaf
402,00

Beschrijving

DJGear Showgear PSA-32A6S Krachtstroom verdeler met uitlezing Bring safety on stage! Power is the most important chain for a successful show on any stage. Showgear developed, together with leading rental companies, the power distributors that will keep your power and equipment save. The PSA series give you real-time voltage and amperage information during your show. Now you can monitor your setup and make sure that the power is correctly distributed at all times. Specifications Input: 1,5m H07RN-F 5G6 cable + CEE male 3P+N+PE, 400VAC, 50/60Hz Output: 6x Schuko 1P+N+PE, 230VAC, 50/60Hz RCCB (1pcs) Rating: 40A Sensitivity: 30mA Class: A Poles: 3P+N Breaking Capacity: 6KA MCB (6pcs) Rated Current: 16A Tripping Curve: C-type Poles: 1P Breaking Capacity: 6KA Physical Color: Dark Grey Housing: Powder coated Metal Dimensions: 483 x 135 x 245 mm IP Rating: IP20 Operating Temp: -5 ~ 40°C Weight: 9,50 Kg

Vergelijk aanbieders (2)

Shop
Prijs
Verzendkosten
Totale prijs
 402,00
Gratis
 402,00
Naar shop
Gratis Shipping Costs
 455,95
€ 24,95
 480,90
Naar shop
€ 24,95 Shipping Costs
Beschrijving (1)

Showgear PSA-32A6S Krachtstroom verdeler met uitlezing Bring safety on stage! Power is the most important chain for a successful show on any stage. Showgear developed, together with leading rental companies, the power distributors that will keep your power and equipment save. The PSA series give you real-time voltage and amperage information during your show. Now you can monitor your setup and make sure that the power is correctly distributed at all times. Specifications Input: 1,5m H07RN-F 5G6 cable + CEE male 3P+N+PE, 400VAC, 50/60Hz Output: 6x Schuko 1P+N+PE, 230VAC, 50/60Hz RCCB (1pcs) Rating: 40A Sensitivity: 30mA Class: A Poles: 3P+N Breaking Capacity: 6KA MCB (6pcs) Rated Current: 16A Tripping Curve: C-type Poles: 1P Breaking Capacity: 6KA Physical Color: Dark Grey Housing: Powder coated Metal Dimensions: 483 x 135 x 245 mm IP Rating: IP20 Operating Temp: -5 ~ 40°C Weight: 9,50 Kg


Productspecificaties

Merk Showtec
EAN
  • 8717748394934
Lengte
  • 0.50 m
Aantal 230v stopcontacten
  • 6
Aantal krachtstroom outputs
  • geen
Type stroomconnector male
  • CEE 5p 32 A male
Type stroomconnector female
  • Europese randaarde contra stekker
Gewicht (incl. verpakking)
  • 8,2 kg
Afmeting (incl. verpakking)
  • 57,0 x 50,0 x 23,0 cm
Max. stroom per fase
  • 32 Amp\xc3\xa8re (7360 Watt)
Max. stroom per uitgang
  • 16 Amp\xc3\xa8re (3680 Watt)
Behuizing
  • metaal
IP-classificatie
  • IP20
Omgevingstemperatuur
  • -5\xc2\xb0C tot +40\xc2\xb0C
Afmetingen
  • 483 x 245 x 135 mm
