Waveshare MLX90640 IR Array Thermal Imaging Camera 32x24 Pixels 110Field of View Communicating via I2C Interface Supports Raspberry Pi in Miscellaneous Industrial or Intelligent Control Applications

By utilizing the MLX90640 far-infrared thermal sensor array, this module can detect the IR distribution of objects in the field of view, turn the data into surface temperature of the objects by calculation, and then generate thermal images. Due to the small form factor, it can be easily integrated into miscellaneous industrial or intelligent control applications. Adopts MLX90640 far-infrared thermal sensor array, 32×24 pixels. Communicating via I2C interface, configurable to fast mode (up to 1MHz data rate). Noise Equivalent Temperature Difference (NETD) 0.1K RMS @1Hz refresh rate. Onboard voltage translator, compatible with 3.3V/5V operating voltage. Applications:High precision non-contact temperature measurements; IR thermal imaging devices, IR thermometers; Smart home, intelligent building, intelligent lighting; Industrial temperature control, security monitoring, intrude/movement detection.
