Delock 62704 3,5 converter SATA 22 pins / SFF 8643 NVMe > 1 x M.2 sleutel M + B

Onlinekabelshop.nl

Description This Delock converter enables the connection of a M.2 SSD in 2280, 2260, 2242 and 2230 format with key B and a M.2 SSD in 2280, 2260, 2242 and 2230 format with key M. It allows the possibility to connect a M.2 SSD based on PCIe and M.2 SSD based on SATA at the same time. The converter can be installed into your system internally through the SATA 22 pin interface while using a SATA M.2 SSD, or via the SFF-8643 interface while using a PCIe M.2 SSD. Specification• Connectors: 1 x SATA 6 Gb/s 22 pin plug (for SATA SSDs) 1 x 36 pin SFF-8643 female (for PCIe SSDs 2 or 4 lanes) 1 x 67 pin M.2 key M slot (PCIe SSD) 1 x 67 pin M.2 key B slot (SATA SSD)• Interface: SATA / PCIe (2 or 4 lanes)• Supports M.2 modules in format 2280, 2260, 2242 and 2230 with key M or key B+M based on PCIe or SATA• Maximum height of the components on the module: 1.5 mm, application of double-sided assembled modules supported• SATA 15 pin power connector always necessary• LEDs for power and activity• Supports NVM Express (NVMe)• Maximum output current:4 A (PCIe) and 3 A (SATA) System requirements • Linux Kernel 3.16 or above• Windows 7/7-64/8.1/8.1-64/10/10-64/11• A free SATA 22 pin interface• A free SFF-8643 interface (PCIe SSD) Package content • 3.5″ converter• Mounting material• User manual

Bol Partner

DeLOCK 62704. Hostinterface: SATA, Output interface: M.2. Data transfer snelheid (max): 6 Gbit/s. Ondersteunt Windows: Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise.... Type verpakking: Doos

Alternate

Deze Delock converter maakt het mogelijk een PCI M.2 SSD en een SATA M.2 SSD aan te sluiten. De converter kan worden geïnstalleerd in een systeem via de SATA 22 pin-interface of de SFF-8643 interface, afhankelijk van de SSD.

Azerty

Bestel direct dé Delock Converter SATA 22 pin SFF-8643 NVMe > 1 x M.2 NGFF Key M + 1 x M.2 NGFF Key B - Storage bay adapter
