YHDC split core current transformer SCT010T D 50A/5V 2%
Prijzen vanaf
Amazon
Split core current transformer Model: SCT010T-D Work voltage: 720V Rated input: 50A Max. Input: 100%（continuous)/150%(1min) Rated output: 5V DC Accuracy: ±2 % Output ripple voltage : ≤5% Output voltage Material of core: Ferrite Work temperature: -25 ℃ ~ + 60 ℃ Storage temperature: -30 ℃ ~ + 90 ℃ Frequency range: 50Hz～60Hz Dielectric strength: AC 3500V/1min Output impedance: 7kΩ Isolation impedance :＞100MΩ(500V DC) Weight: 42g 5V DC output, split core current transformer. Suspended installation, crimping terminal output.
Lees meer
8,04
Beschrijving
Amazon
Split core current transformer Model: SCT010T-D Work voltage: 720V Rated input: 50A Max. Input: 100%（continuous)/150%(1min) Rated output: 5V DC Accuracy: ±2 % Output ripple voltage : ≤5% Output voltage Material of core: Ferrite Work temperature: -25 ℃ ~ + 60 ℃ Storage temperature: -30 ℃ ~ + 90 ℃ Frequency range: 50Hz～60Hz Dielectric strength: AC 3500V/1min Output impedance: 7kΩ Isolation impedance :＞100MΩ(500V DC) Weight: 42g 5V DC output, split core current transformer. Suspended installation, crimping terminal output.
Vergelijk aanbieders (1)
Shop
Prijs
Verzendkosten
Totale prijs
Beschrijving
(1)
Split core current transformer Model: SCT010T-D Work voltage: 720V Rated input: 50A Max. Input: 100%（continuous)/150%(1min) Rated output: 5V DC Accuracy: ±2 % Output ripple voltage : ≤5% Output voltage Material of core: Ferrite Work temperature: -25 ℃ ~ + 60 ℃ Storage temperature: -30 ℃ ~ + 90 ℃ Frequency range: 50Hz～60Hz Dielectric strength: AC 3500V/1min Output impedance: 7kΩ Isolation impedance :＞100MΩ(500V DC) Weight: 42g 5V DC output, split core current transformer. Suspended installation, crimping terminal output.
Productspecificaties
